5040TIPHK-CP
1-1/2" PVC Offset Tip-Toe Waste & Overflow, Bell faceplate, Half Kit
Tip-Toe
Barcode: 775439000913
Description
1-1/2" PVC offset-drain bath waste & overflow with a Tip-Toe stopper and bell SlideOn™ faceplate, supplied as a half kit, without pipe or joining fitting. Features a spin-on tie plate, angle adapter, foam overflow gasket, and coarse-thread strainer.
Features
- Bell SlideOn™ Faceplate
- Thick foam overflow gasket with adhesive back
- Spin-on tie plate for a toolless installation
- Overflow head featuring an integrated 6 degree angle
- Overflow head featuring aggressive threads for a quicker and easier installation
- Angle Adapter included. Use optional
- Self clinging rubber waste gasket
- Coarse thread strainer
Specs
- Length: HALF KIT
- Material: PVC
- Carton Quantity: 20
Downloads
Install Instructions
